Adet bazlı fiyat
- 1+ adet$5.90
- 10+ adet$5.57
- 100+ adet$5.25
- 500+ adet$4.96
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Ingress Protection
- IP40
- Number Of Poles
- 1
- Actuator Material
- Plastic
- Orientation
- Straight
- Max Current Rating
- 7A
- HTS Kodu
- 8536.50.70.00
- Switch Function
- On-Mom
- Contact Currentdcmax
- 7A
- Akım Değeri
- 7A
- Contact Materials
- Silver
- Pretravelmax
- 0.6 mm
- Contact Plating
- Gold
- Pretravel
- 0.024 (0.6mm)
- Genişlik
- 5.1mm
- Seri
- J
- Çalışma Sıcaklığı
- -10°C~80°C
- Max Voltage Rating Ac
- 250V
- Electricallife
- 50,000 Cycles
- Montaj Tipi
- Chassis Mount
- Current Rating Amps
- 7A AC
- Depth
- 5.1mm
- Contact Ac Max Rating R Load
- 7A@250VAC
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Montaj
- Chassis Mount, Panel, Screw
- Yükseklik
- 10.4mm
- Actuator Type
- Round (Pin Plunger)
- Terminal
- Solder
- Release Force
- 28gf
- Operating Position
- 0.319 (8.1mm)
- Kurşunsuz
- Lead Free
- Parça Durumu
- Active
- Overtravel
- 0.004 (0.1mm)
- Voltage Rated Ac
- 250V
- Fabrika Tedarik Süresi
- 10 Weeks
- ECCN Kodu
- EAR99
- Differential Travel
- 0.006 (0.15mm)
- Nem Hassasiyeti (MSL)
- Not Applicable
- Mechanical Life
- 10,000,000 Cycles
- Ambalaj
- Bulk
- Contact Current Rating
- 7A
