G7L-2A-TUB-CB-DC12

Teknik Özellikler

Montaj

Brackets, Chassis Mount

Coilresistance

75Ohm

Coil Voltage Dc

12V

Body Height

47mm

Contact Materials

Silver Tin Indium (AgSnIn)

Coilinput Supply Type

DC

Power Consumption

1.9W

Must Operate Voltage

9VDC

RoHS Durumu

RoHS Compliant

Kurşunsuz

Lead Free

Coil Type

Non Latching

Max Voltage Rating Ac

250V

Nem Hassasiyeti (MSL)

Not Applicable

Relay Type

General Purpose

Terminal Stili

Quick Connect - 0.250 (6.3mm)

Body Breadth

33.5 mm

Body Length Or Diameter

68.5mm

Max Current Rating

25A

Kontak Formu

DPST-NO (2 Form A)

Reference Standard

CE; CSA; TUV; UL

Contactoutput Supply Type

AC

Coil Current

158mA

Throw Configuration

DPST

Terminal

Quick Connect

Coil Insulation

Class B

Must Release Voltage

1.8VDC

Contact Currentacmax

30A

Radyasyon Dayanımı

No

Seri

G7L

Switching Voltage

250VAC -Max

Coil Power

1.9W

Operate Time

30ms

Fabrika Tedarik Süresi

18 Weeks

Electricallife

100000 Cycle(s)

Contact Ac Max Rating R Load

30A@220VAC

Coil Voltage

12VDC

Relay Action

MOMENTARY

Montaj Tipi

Chassis Mount

Release Time

30 ms

ECCN Kodu

EAR99
