Fiyat için teklif alın
Adet ve teslim süresine göre fiyatlandırılır.
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Seal Rating
- Sealed - Flux Protection
- Contact Materials
- Silver Nickel (AgNi)
- Electricallife
- 50000 Cycle(s)
- Length Termination
- 0.0032 inch
- Must Operate Voltage
- 4.2VDC
- Operate Time
- 10ms
- Physical Dimension
- 28.5mm x 10mm x 12.3mm
- Çalışma Sıcaklığı
- -40°C~85°C
- ECCN Kodu
- EAR99
- Coilinput Supply Type
- DC
- Coil Power
- 220mW
- Weight
- 7.8g
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Montaj Tipi
- Through Hole
- Coil Voltage
- 6VDC
- Contact Voltagedcmax
- 24V
- RoHS Durumu
- RoHS Compliant
- Seri
- G6RL
- Kontak Formu
- SPST-NO (1 Form A)
- Body Breadth
- 10 mm
- Contact Voltageacmax
- 250V
- Yüzey Montaj
- NO
- Terminal Sayısı
- 4
- Contact Resistance
- 100mOhm
- Contact Rating Current
- 10A
- Dielectric Strength Between Coil And Contacts
- 5000 Vrms
- Coil Current
- 36.7mA
- Insulation Resistance
- 1000000000Ohm
- Contact Ac Max Rating R Load
- 8A@250VAC
- Packing Method
- TRAY
- Pcb Hole Count
- 4
- Ambalaj
- Bulk
- Yayın Yılı
- 2001
- Coil Type
- Non Latching
- Switching Voltage
- 250VAC - Nom
- Contact Dc Max Rating R Load
- 5A@24VDC
- Input Switching Control Type
- Random
- HTS Kodu
- 8536.41.00.20
- Terminal Stili
- PC Pin
- Relay Action
- MOMENTARY
