Adet bazlı fiyat
- 1+ adet$2.93
- 10+ adet$2.77
- 100+ adet$2.61
- 500+ adet$2.46
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Terminal Sayısı
- 5
- Contact Rating Current
- 8A
- Contact Resistance
- 100mOhm
- Insulation Resistance
- 1000000000Ohm
- Coil Current
- 9.2mA
- Packing Method
- TRAY
- Ambalaj
- Bulk
- Pin Sayısı
- 5
- Pcb Hole Count
- 5
- Yayın Yılı
- 2001
- Coil Type
- Non Latching
- Input Switching Control Type
- Random
- Switching Voltage
- 250VAC - Nom
- Genişlik
- 10mm
- Relay Action
- MOMENTARY
- Max Voltage Rating Dc
- 300V
- Terminal Stili
- PC Pin
- Must Release Voltage
- 2.4VDC
- Dielectric Strength Between Open Contacts
- 1000 Vrms
- Fabrika Tedarik Süresi
- 12 Weeks
- Parça Durumu
- Active
- Body Height
- 12.3mm
- Relay Type
- General Purpose
- Coilresistance
- 2.62kOhm
- Release Time
- 5ms
- Reference Standard
- CUL; UL; VDE
- Kurşunsuz Kodu
- yes
- Contactoutput Supply Type
- AC/DC
- Max Voltage Rating Ac
- 400V
- Seal Rating
- Sealed - Fully
- Length Termination
- 0.0032 inch
- Operate Time
- 10ms
- Must Operate Voltage
- 16.8VDC
- Coil Voltage Dc
- 24V
- Contact Materials
- Silver Tin Indium (AgSnIn)
- Çalışma Sıcaklığı
- -40°C~85°C
- Terminal
- PC Pin
- Montaj
- Through Hole
- Coil Power
- 220mW
- Coilinput Supply Type
- DC
