Adet bazlı fiyat
- 1+ adet$6.83
- 10+ adet$6.44
- 100+ adet$6.08
- 500+ adet$5.73
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Nem Hassasiyeti (MSL)
- Not Applicable
- Ambalaj
- Tube
- Çalışma Sıcaklığı
- -40°C~70°C
- Operate Time
- 5ms
- Max Voltage Rating Ac
- 250V
- Throw Configuration
- DPDT
- Yayın Yılı
- 1998
- Coil Power
- 360mW
- Montaj Tipi
- Through Hole
- Montaj
- Through Hole
- Contact Rating Current
- 1A
- Contactoutput Supply Type
- AC/DC
- Relay Type
- General Purpose
- ECCN Kodu
- EAR99
- Max Current Rating
- 2A
- Kontak Formu
- DPDT (2 Form C)
- Fabrika Tedarik Süresi
- 13 Weeks
- Radyasyon Dayanımı
- No
- Reference Standard
- CSA; UL
- Relay Action
- LATCHED
- Seri
- G6A
- Coil Current
- 30mA
- Max Voltage Rating Dc
- 220V
- Contact Ac Max Rating R Load
- .6A@125VAC
- HTS Kodu
- 8536.41.00.20
- Power Consumption
- 360mW
- Coil Voltage Dc
- 12V
- Contact Materials
- Silver Palladium (AgPd), Gold (Au)
- Release Time
- 5.5 ms
- Coilinput Supply Type
- DC
- Switching Voltage
- 250VAC 220VDC -Max
- Terminal
- PC Pin
- RoHS Durumu
- RoHS Compliant
- Parça Durumu
- Active
- Body Height
- 8.4mm
- Pin Sayısı
- 10
- Coil Voltage
- 12VDC
- Coil Type
- Latching, Dual Coil
- Body Length Or Diameter
- 20.2mm
- Terminal Stili
- PC Pin
