Adet bazlı fiyat
- 1+ adet$15.39
- 10+ adet$14.51
- 100+ adet$13.69
- 500+ adet$12.92
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Contact Ac Max Rating R Load
- 5A@250VAC
- Çalışma Sıcaklığı
- -40°C~70°C
- Pin Sayısı
- 8
- Contact Materials
- Silver Alloy
- Depth
- 13.5mm
- Terminal
- PC Pin
- Radyasyon Dayanımı
- No
- Contact Currentdcmax
- 5A
- Seal Rating
- Sealed - Fully
- Additional Feature
- COIL OPERATE VOLTAGE(AC): 192 V, COIL RELEASE VOLTAGE(AC): 72 V
- Must Release Voltage
- 72VAC
- Terminal Stili
- PC Pin
- Coilinput Supply Type
- AC
- Reference Standard
- CSA; SEMKO; TUV; UL; VDE
- Kurşunsuz
- Lead Free
- Max Voltage Rating Ac
- 380V
- Max Current Rating
- 4A
- Relay Type
- General Purpose
- Contact Currentacmax
- 5A
- ECCN Kodu
- EAR99
- Coilresistance
- 30kOhm
- Coil Type
- Non Latching
- Contact Dc Max Rating R Load
- 5A@30VDC
- Ambalaj
- Tray
- Coil Power
- 900mW
- Parça Durumu
- Active
- Operate Time
- 15ms
- Must Operate Voltage
- 192VAC
- Throw Configuration
- DPDT
- Switching Voltage
- 380VAC 125VDC -Max
- Body Height
- 25.5mm
- Montaj Tipi
- Through Hole
- Contactoutput Supply Type
- AC/DC
- Physical Dimension
- 29mm x 13mm x 25.5mm
- Coil Current
- 3.8mA
- Body Breadth
- 13 mm
- Coil Voltage Ac
- 240V
- Kılıf / Paket
- DIP
- Fabrika Tedarik Süresi
- 15 Weeks
- Seri
- G2R
