Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Max Voltage Rating Ac
- 380V
- Body Breadth
- 13 mm
- Coil Current
- 4.8mA
- Reference Standard
- CSA; SEMKO; TUV; UL; VDE
- Physical Dimension
- 29mm x 13mm x 25.5mm
- Coilinput Supply Type
- DC
- Contactoutput Supply Type
- AC/DC
- Terminal Stili
- PC Pin
- Must Release Voltage
- 16.5VDC
- Seal Rating
- Sealed - Flux Protection
- Montaj Tipi
- Through Hole
- Radyasyon Dayanımı
- No
- Terminal
- PC Pin
- Contact Materials
- Silver Alloy
- Switching Voltage
- 380VAC 125VDC -Max
- Body Height
- 25.5mm
- Throw Configuration
- SPDT
- Pin Sayısı
- 8
- Çalışma Sıcaklığı
- -40°C~70°C
- Must Operate Voltage
- 77VDC
- Parça Durumu
- Active
- Operate Time
- 15ms
- Contact Ac Max Rating R Load
- 16A@250VAC
- Coil Power
- 530mW
- Max Voltage Rating Dc
- 125V
- Body Length Or Diameter
- 29mm
- Release Time
- 5ms
- RoHS Durumu
- RoHS Compliant
- Yayın Yılı
- 2002
- Montaj
- Through Hole
- Contact Dc Max Rating R Load
- 16A@30VDC
- Ambalaj
- Tray
- Coil Type
- Non Latching
- Coilresistance
- 22.9kOhm
- Coil Voltage
- 110VDC
- Kurşunsuz Kodu
- yes
- ECCN Kodu
- EAR99
- Relay Action
- MOMENTARY
- Kontak Formu
- SPDT (1 Form C)
- Nem Hassasiyeti (MSL)
- Not Applicable
