Teknik Özellikler
- Max Voltage Rating Ac
- 380V
- Weight
- 17g
- Kurşunsuz
- Lead Free
- Coilinput Supply Type
- DC
- Reference Standard
- CSA; SEMKO; TUV; UL; VDE
- Terminal Stili
- PC Pin
- Must Release Voltage
- 0.75VDC
- Seal Rating
- Sealed - Flux Protection
- Electricallife
- 100000 Cycle(s)
- Depth
- 13mm
- Contact Materials
- Silver Alloy
- Input Switching Control Type
- Random
- Terminal
- PC Pin
- Pin Sayısı
- 6
- Çalışma Sıcaklığı
- -40°C~70°C
- Insulation Resistance
- 1000000000Ohm
- Contact Resistance
- 50mOhm
- Coil Power
- 530mW
- ECCN Kodu
- EAR99
- Ambalaj
- Tray
- Coil Type
- Non Latching
- Coilresistance
- 47Ohm
- Max Current Rating
- 16A
- Relay Type
- General Purpose
- Coil Current
- 106mA
- Dielectric Strength Between Open Contacts
- 1000 Vrms
- Dielectric Strength Between Coil And Contacts
- 5000 Vrms
- Physical Dimension
- 29mm x 13mm x 25.5mm
- Montaj Tipi
- Through Hole
- Contactoutput Supply Type
- AC/DC
- Body Height
- 25.5mm
- Switching Voltage
- 380VAC 125VDC -Max
- Terminal Sayısı
- 6
- Throw Configuration
- SPST
- Must Operate Voltage
- 3.5VDC
- Parça Durumu
- Active
- Operate Time
- 15ms
- Max Voltage Rating Dc
- 125V
- Voltage Rated Ac
- 380V
- Release Time
- 5ms
