Adet bazlı fiyat
- 1+ adet$4.15
- 10+ adet$3.92
- 100+ adet$3.69
- 500+ adet$3.48
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Çalışma Sıcaklığı
- -40°C~70°C
- Contact Ac Max Rating R Load
- 10A@250VAC
- Input Switching Control Type
- Random
- Terminal
- PC Pin
- Electricallife
- 100000 Cycle(s)
- Contact Materials
- Silver Alloy
- Pin Sayısı
- 4
- Reference Standard
- CSA; SEMKO; TUV; UL; VDE
- Coilinput Supply Type
- DC
- Terminal Stili
- PC Pin
- Must Release Voltage
- 7.2VDC
- Seal Rating
- Sealed - Flux Protection
- Max Voltage Rating Ac
- 380V
- Weight
- 17g
- Kurşunsuz
- Lead Free
- Relay Type
- General Purpose
- Max Current Rating
- 10A
- Contact Dc Max Rating R Load
- 10A@30VDC
- Ambalaj
- Tray
- Coilresistance
- 4.17kOhm
- Coil Type
- Non Latching
- ECCN Kodu
- EAR99
- Contact Resistance
- 50mOhm
- Coil Power
- 530mW
- Insulation Resistance
- 1000000000Ohm
- Body Length Or Diameter
- 29mm
- Must Operate Voltage
- 33.6VDC
- Parça Durumu
- Active
- Operate Time
- 15ms
- Terminal Sayısı
- 6
- Body Height
- 25.5mm
- Switching Voltage
- 380VAC 125VDC -Max
- Throw Configuration
- SPST
- Physical Dimension
- 29mm x 13mm x 25.5mm
- Dielectric Strength Between Coil And Contacts
- 5000 Vrms
- Contactoutput Supply Type
- AC/DC
- Montaj Tipi
- Through Hole
- Dielectric Strength Between Open Contacts
- 1000 Vrms
- Body Breadth
- 13 mm
- Coil Current
- 11.5mA
