Teknik Özellikler
- Contact Ac Max Rating R Load
- 10A@250VAC
- Parça Durumu
- Active
- Operate Time
- 15ms
- Çalışma Sıcaklığı
- -40°C~70°C
- Must Operate Voltage
- 176VAC
- Throw Configuration
- SPST
- Pin Sayısı
- 4
- Terminal
- PC Pin
- Radyasyon Dayanımı
- No
- Contact Materials
- Silver Alloy
- Switching Voltage
- 380VAC 125VDC -Max
- Body Height
- 25.5mm
- Seal Rating
- Sealed - Flux Protection
- Additional Feature
- COIL OPERATE VOLTAGE(AC): 176 V, COIL RELEASE VOLTAGE(AC): 66 V
- Must Release Voltage
- 66VAC
- Terminal Stili
- PC Pin
- Contactoutput Supply Type
- AC/DC
- Montaj Tipi
- Through Hole
- Reference Standard
- CSA; SEMKO; TUV; UL; VDE
- Physical Dimension
- 29mm x 13mm x 25.5mm
- Coilinput Supply Type
- AC
- Body Breadth
- 13 mm
- Coil Current
- 4.1mA
- Max Voltage Rating Ac
- 380V
- Coil Voltage Ac
- 220V
- Relay Type
- General Purpose
- Fabrika Tedarik Süresi
- 18 Weeks
- Max Current Rating
- 10A
- Seri
- G2R
- Relay Action
- MOMENTARY
- Kontak Formu
- SPST-NO (1 Form A)
- Nem Hassasiyeti (MSL)
- Not Applicable
- Coil Type
- Non Latching
- Coilresistance
- 25kOhm
- Contact Dc Max Rating R Load
- 10A@30VDC
- Ambalaj
- Tray
- ECCN Kodu
- EAR99
- Coil Voltage
- 220VAC
- Kurşunsuz Kodu
- yes
- RoHS Durumu
- RoHS Compliant
