Adet bazlı fiyat
- 1+ adet$1.48
- 10+ adet$1.39
- 100+ adet$1.31
- 500+ adet$1.24
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Yayın Yılı
- 1999
- Voltage Rated Dc
- 30V
- Montaj
- Chassis Mount, Screw
- RoHS Durumu
- RoHS Compliant
- Voltage Rated Ac
- 250V
- Overtravel
- 0.062 (1.6mm)
- Differential Travel
- 0.060 (1.5mm)
- Max Voltage Rating Dc
- 250V
- Reach Svhc
- Unknown
- Fabrika Tedarik Süresi
- 16 Weeks
- Seri
- D3V
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Uzunluk
- 50.2mm
- Kurşunsuz Kodu
- yes
- Montaj Tipi
- Chassis Mount
- Genişlik
- 10.3mm
- Pretravelmax
- 4 mm
- Contact Current Rating
- 16A
- HTS Kodu
- 8536.50.90.40
- Actuator Type
- Lever, Roller
- Circuit
- SPDT
- Parça Durumu
- Active
- Body Height
- 15.9mm
- Mechanical Life
- 10,000,000 Cycles
- Akım Değeri
- 16A
- Orientation
- Straight
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Insulation Resistance
- 100MOhm
- Pretravel
- 0.157 (4.0mm)
- Contact Resistance
- 30mOhm
- Release Force
- 14gf
- Max Current Rating
- 16A
- Operating Force
- 125gf
- Actuator Material
- Polyacetal, Resin, Stainless Steel
- ECCN Kodu
- EAR99
- Ambalaj
- Bulk
- Contact Dc Max Rating R Load
- 16A@8VDC
- Terminal Stili
- Quick Connect - 0.250 (6.3mm)
- Ingress Protection
- IP40
- Sealing
- IP00
