Adet bazlı fiyat
- 1+ adet$1.09
- 10+ adet$1.03
- 100+ adet$0.97
- 500+ adet$0.92
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Montaj Tipi
- Chassis Mount
- Terminal Stili
- Quick Connect - 0.250 (6.3mm)
- Pretravelmax
- 1.6 mm
- Ingress Protection
- IP40
- Contact Current Rating
- 16A
- Sealing
- IP00
- Max Voltage Rating Ac
- 250V
- Operating Position
- 0.600 (15.2mm)
- Circuit
- SPST-NO
- Actuator Type
- Lever, Straight
- HTS Kodu
- 8536.50.90.40
- Contact Ac Max Rating R Load
- 16A@250VAC
- Parça Durumu
- Active
- Current Rating Amps
- 16A AC 10A DC
- Çalışma Sıcaklığı
- -25°C~105°C
- Switch Function
- Off-Mom
- Throw Configuration
- SPST
- Body Height
- 15.9mm
- Contact Materials
- Silver
- Electricallife
- 100,000 Cycles
- Depth
- 10.3mm
- Terminal
- Quick Connect
- Montaj
- Chassis Mount
- Voltage Rated Dc
- 30V
- Yayın Yılı
- 2002
- RoHS Durumu
- RoHS Compliant
- Akım Değeri
- 10A
- Mechanical Life
- 10,000,000 Cycles
- Overtravel
- 0.031 (0.79mm)
- Voltage Rated Ac
- 250V
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Differential Travel
- 0.025 (0.6mm)
- Max Voltage Rating Dc
- 250V
- Pretravel
- 0.063 (1.6mm)
- Release Force
- 50gf
- Max Current Rating
- 16A
- Reach Svhc
- Unknown
- Operating Force
- 200gf
- Fabrika Tedarik Süresi
- 15 Weeks
- Seri
- D3V
