Teknik Özellikler
- Montaj Tipi
- Chassis Mount
- Terminal Stili
- Quick Connect - 0.187 (4.7mm)
- Body Breadth
- 10.3 mm
- Ingress Protection
- IP40
- Contact Current Rating
- 16A
- Sealing
- IP00
- Actuator Type
- Lever, Straight
- Contact Voltagedcmax
- 8V
- HTS Kodu
- 8536.50.90.40
- Operating Position
- 0.600 (15.2mm)
- Circuit
- SPDT
- Parça Durumu
- Active
- Contact Ac Max Rating R Load
- 16A@250VAC
- Current Rating Amps
- 16A AC 10A DC
- Çalışma Sıcaklığı
- -25°C~105°C
- Switch Function
- On-Mom
- Electricallife
- 100,000 Cycles
- Contact Materials
- Silver
- Body Height
- 15.9mm
- Terminal
- Quick Connect
- Voltage Rated Dc
- 30V
- Yayın Yılı
- 2002
- Montaj
- Chassis Mount
- Akım Değeri
- 10A
- Mechanical Life
- 10,000,000 Cycles
- RoHS Durumu
- RoHS Compliant
- Overtravel
- 0.031 (0.79mm)
- Voltage Rated Ac
- 250V
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Differential Travel
- 0.025 (0.6mm)
- Body Length Or Diameter
- 27.8mm
- Pretravel
- 0.063 (1.6mm)
- Release Force
- 15gf
- Reach Svhc
- Unknown
- Fabrika Tedarik Süresi
- 15 Weeks
- Operating Force
- 100gf
- Seri
- D3V
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Kurşunsuz Kodu
- yes
- ECCN Kodu
- EAR99
