Teknik Özellikler
- Overtravel
- 0.062 (1.6mm)
- Kurşunsuz Kodu
- yes
- Ratings
- Dust Tight, IP67, Waterproof
- Voltage Rated Dc
- 30V
- Contact Current Rating
- 5A
- Montaj
- Chassis Mount, Panel, Screw, Solder
- ECCN Kodu
- EAR99
- Contact Currentacmax
- 5A
- Body Height
- 33mm
- Ingress Protection
- IP67 - Dust Tight, Waterproof
- Seri
- D2VW
- Contact Ac Max Rating R Load
- 5A@250VAC
- HTS Kodu
- 8536.50.70.00
- Orientation
- Straight
- Body Breadth
- 10.3 mm
- Parça Durumu
- Active
- Differential Travel
- 0.031 (0.8mm)
- Actuator Type
- Lever, Simulated Roller
- Mechanical Life
- 10,000,000 Cycles
- Operating Force
- 120gf
- Current Rating Amps
- 5A AC/DC
- Contact Dc Max Rating R Load
- 5A@30VDC
- JESD-609 Kodu
- e4
- Circuit
- SPDT
- Pretravelmax
- 4 mm
- Yayın Yılı
- 2004
- RoHS Durumu
- RoHS Compliant
- Contact Materials
- Silver
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Radyasyon Dayanımı
- No
- Voltage Rated Ac
- 250V
- Max Voltage Rating Dc
- 125V
- Ambalaj
- Tray
- Terminal Stili
- Solder, Quick Connect - 0.187 (4.7mm)
- Sealing
- IP50
- Release Force
- 15gf
- Switch Function
- On-Mom
- Akım Değeri
- 5A
- Body Length Or Diameter
- 15.9mm
- Actuator Travel
- 5.6 mm
