Adet bazlı fiyat
- 1+ adet$5.34
- 10+ adet$5.04
- 100+ adet$4.76
- 500+ adet$4.49
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Ratings
- Dust Tight, IP50, IP67, Waterproof
- Voltage Rated Dc
- 30V
- Yayın Yılı
- 2004
- Weight
- 7g
- Overtravel
- 0.040 (1.0mm)
- Genişlik
- 10.3mm
- Terminal Stili
- Solder, Quick Connect - 0.187 (4.7mm)
- Orientation
- Straight
- Release Force
- 30gf
- Insulation Resistance
- 100MOhm
- Contact Materials
- Silver
- ECCN Kodu
- EAR99
- RoHS Durumu
- RoHS Compliant
- Contact Current Rating
- 5A
- Montaj
- Chassis Mount, Screw, Solder
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Ingress Protection
- IP67 - Dust Tight, Waterproof
- Voltage Rated Ac
- 125V
- Depth
- 10.3mm
- Seri
- D2VW
- Ambalaj
- Bulk
- Max Voltage Rating Dc
- 125V
- Uzunluk
- 41.4mm
- Montaj Tipi
- Chassis Mount
- Mechanical Life
- 10,000,000 Cycles
- Fabrika Tedarik Süresi
- 11 Weeks
- Switch Function
- On-Mom
- Reach Svhc
- Unknown
- Max Current Rating
- 5A
- Parça Durumu
- Active
- Akım Değeri
- 5A
- Differential Travel
- 0.016 (0.4mm)
- Actuator Type
- Round (Pin Plunger)
- Circuit
- SPDT
- Pretravel
- 0.047 (1.2mm)
- Max Voltage Rating Ac
- 250V
- Çalışma Sıcaklığı
- -40°C~85°C
- Operating Position
- 0.579 (14.7mm)
- Terminal
- Solder
- Electricallife
- 100,000 Cycles
