Teknik Özellikler
- Current Rating Amps
- 100mA AC/DC
- Operating Force
- 120gf
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Terminal
- Solder
- Electricallife
- 1,000,000 Cycles
- Operating Position
- 0.815 (20.7mm)
- Çalışma Sıcaklığı
- -40°C~85°C
- Circuit
- SPDT
- Pretravel
- 0.157 (4.0mm)
- Max Voltage Rating Ac
- 125V
- Differential Travel
- 0.031 (0.8mm)
- Actuator Type
- Lever, Roller
- Akım Değeri
- 100mA
- Reach Svhc
- Unknown
- Parça Durumu
- Active
- Switch Function
- On-Mom
- Mechanical Life
- 10,000,000 Cycles
- Fabrika Tedarik Süresi
- 10 Weeks
- Montaj Tipi
- Chassis Mount
- Seri
- D2VW
- Ambalaj
- Bulk
- Max Voltage Rating Dc
- 30V
- Ingress Protection
- IP67 - Dust Tight, Waterproof
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Contact Materials
- Gold
- ECCN Kodu
- EAR99
- RoHS Durumu
- RoHS Compliant
- Contact Current Rating
- 100mA
- Montaj
- Chassis Mount, Screw, Solder
- Release Force
- 15gf
- Kılıf / Paket
- 100
- Orientation
- Straight
- Terminal Stili
- Solder, Quick Connect - 0.187 (4.7mm)
- Overtravel
- 0.062 (1.6mm)
- Yayın Yılı
- 2004
- Voltage Rated Dc
- 30V
- Ratings
- IP67
