Teknik Özellikler
- Throw Configuration
- DPST
- Overtravel
- 0.062 (1.6mm)
- Yayın Yılı
- 2012
- Voltage Rated Dc
- 30V
- Kurşunsuz Kodu
- yes
- Actuator Material
- Stainless Steel
- Max Voltage Rating Dc
- 30V
- Ambalaj
- Bulk
- Seri
- D2T
- Body Height
- 24.65mm
- Depth
- 16mm
- Ingress Protection
- IP40
- Voltage Rated Ac
- 125V
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Contact Currentacmax
- 5A
- RoHS Durumu
- RoHS Compliant
- Montaj
- Chassis Mount, Panel, Screw, Solder
- Contact Materials
- Silver
- ECCN Kodu
- EAR99
- Release Force
- 20gf
- Orientation
- Right Angle
- Terminal Stili
- Quick Connect - 0.110 (2.8mm)
- Contact Ac Max Rating R Load
- 5A@250VAC
- HTS Kodu
- 8536.50.70.00
- Actuator Type
- Lever, Straight
- Akım Değeri
- 6A
- Parça Durumu
- Active
- Max Current Rating
- 5A
- Body Breadth
- 12.5 mm
- Switch Function
- Off-Mom
- Fabrika Tedarik Süresi
- 11 Weeks
- Mechanical Life
- 100,000 Cycles
- Montaj Tipi
- Chassis Mount
- Uzunluk
- 34.4mm
- Contact Dc Max Rating R Load
- 6A@30VDC
- Current Rating Amps
- 5A AC 6A DC
- REACH Uyumluluk Kodu
- unknown
- Operating Force
- 150gf
- Nem Hassasiyeti (MSL)
- Not Applicable
- Electricallife
- 100,000 Cycles
