Adet bazlı fiyat
- 1+ adet$2.24
- 10+ adet$2.11
- 100+ adet$1.99
- 500+ adet$1.88
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Montaj Tipi
- Through Hole
- Mechanical Life
- 1,000,000 Cycles
- Fabrika Tedarik Süresi
- 19 Weeks
- Uzunluk
- 19.8mm
- Akım Değeri
- 2A
- Actuator Type
- Lever, Straight
- Differential Travel
- 0.031 (0.8mm)
- Switch Function
- On-Mom
- Reach Svhc
- Unknown
- Max Current Rating
- 2A
- Parça Durumu
- Active
- Operating Position
- 0.345 (8.8mm)
- Terminal
- PC Pin
- Electricallife
- 50,000 Cycles
- Circuit
- SPDT
- Max Voltage Rating Ac
- 250V
- Çalışma Sıcaklığı
- -20°C~70°C
- Contact Currentdcmax
- 2A
- Current Rating Amps
- 2A AC/DC
- Contact Dc Max Rating R Load
- 2A@30VDC
- Operating Force
- 61gf
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Yayın Yılı
- 2004
- Ratings
- Dust Tight, IP67, Waterproof
- Voltage Rated Dc
- 30V
- Overtravel
- 0.030 (0.76mm)
- Release Force
- 5.099gf
- HTS Kodu
- 8536.50.70.00
- Terminal Stili
- PC Pin
- Contact Ac Max Rating R Load
- 2A@250VAC
- Ingress Protection
- IP67 - Dust Tight, Waterproof
- Voltage Rated Ac
- 250V
- Body Height
- 11mm
- Depth
- 6.4mm
- Max Voltage Rating Dc
- 30V
- Ambalaj
- Bulk
- Seri
- D2SW-P
- Actuator Material
- Stainless Steel
- Contact Materials
- Silver
- ECCN Kodu
- EAR99
