Adet bazlı fiyat
- 1+ adet$0.46
- 10+ adet$0.44
- 100+ adet$0.41
- 500+ adet$0.39
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Contact Currentacmax
- 2A
- RoHS Durumu
- RoHS Compliant
- Contact Current Rating
- 2A
- Montaj
- Through Hole
- Contact Materials
- Silver
- ECCN Kodu
- EAR99
- Ambalaj
- Bulk
- Seri
- D2SW-P
- Body Height
- 11mm
- Ingress Protection
- IP67 - Dust Tight, Waterproof
- Voltage Rated Ac
- 250V
- Terminal Stili
- PC Pin
- Contact Ac Max Rating R Load
- 2A@250VAC
- HTS Kodu
- 8536.50.70.00
- Release Force
- 20gf
- Pretravelmax
- 0.6 mm
- Overtravel
- 0.015 (0.4mm)
- Voltage Rated Dc
- 30V
- Ratings
- Dust Tight, IP67, Waterproof
- Yayın Yılı
- 2004
- Operating Force
- 183gf
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Current Rating Amps
- 2A AC/DC
- Contact Currentdcmax
- 2A
- Çalışma Sıcaklığı
- -20°C~70°C
- Pretravel
- 0.024 (0.6mm)
- Circuit
- SPDT
- Electricallife
- 50,000 Cycles
- Terminal
- PC Pin
- Operating Position
- 0.330 (8.4mm)
- Parça Durumu
- Active
- Reach Svhc
- Unknown
- Body Breadth
- 6.4 mm
- Switch Function
- On-Mom
- Actuator Type
- Round (Pin Plunger)
- Differential Travel
- 0.006 (0.15mm)
- Akım Değeri
- 2A
- Actuator Travel
- 1 mm
- Body Length Or Diameter
- 19.8mm
