Adet bazlı fiyat
- 1+ adet$1.84
- 10+ adet$1.73
- 100+ adet$1.64
- 500+ adet$1.54
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Overtravel
- 0.015 (0.4mm)
- Weight
- 2g
- Pretravelmax
- 0.6 mm
- Yayın Yılı
- 2004
- Ratings
- Dust Tight, IP67, Waterproof
- Voltage Rated Dc
- 30V
- Ingress Protection
- IP67 - Dust Tight, Waterproof
- Voltage Rated Ac
- 125V
- Max Voltage Rating Dc
- 30V
- Ambalaj
- Bulk
- Seri
- D2SW-P
- RoHS Durumu
- RoHS Compliant
- Contact Current Rating
- 100mA
- Montaj
- Chassis Mount, Panel, Screw
- Contact Materials
- Gold
- ECCN Kodu
- EAR99
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Kılıf / Paket
- 100
- Release Force
- 20gf
- Terminal Stili
- Quick Connect - 0.110 (2.8mm)
- HTS Kodu
- 8536.50.70.00
- Orientation
- Straight
- Onay Kuruluşu
- CSA, UL
- Akım Değeri
- 100mA
- Actuator Type
- Round (Pin Plunger)
- Differential Travel
- 0.006 (0.15mm)
- Body Breadth
- 6.4 mm
- Switch Function
- On-Mom
- Parça Durumu
- Active
- Reach Svhc
- Unknown
- Montaj Tipi
- Chassis Mount
- Mechanical Life
- 1,000,000 Cycles
- Fabrika Tedarik Süresi
- 19 Weeks
- Number Of Poles
- 1
- Current Rating Amps
- 100mA AC/DC
- Operating Force
- 183gf
- Nem Hassasiyeti (MSL)
- Not Applicable
- Operating Position
- 0.330 (8.4mm)
- Kurşunsuz
- Lead Free
- Electricallife
- 200,000 Cycles
