Fiyat için teklif alın
Adet ve teslim süresine göre fiyatlandırılır.
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Contact Materials
- Gold
- ECCN Kodu
- EAR99
- RoHS Durumu
- RoHS Compliant
- Contact Current Rating
- 100mA
- Montaj
- Chassis Mount, Panel, Screw
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Contact Currentacmax
- 0.1A
- Ingress Protection
- IP67 - Dust Tight, Waterproof
- Voltage Rated Ac
- 125V
- Body Height
- 11mm
- Depth
- 6.4mm
- Max Voltage Rating Dc
- 30V
- Ambalaj
- Tray
- Seri
- D2SW-P
- Actuator Material
- Stainless Steel
- HTS Kodu
- 8536.50.70.00
- Terminal Stili
- Quick Connect - 0.110 (2.8mm)
- Contact Ac Max Rating R Load
- .1A@125VAC
- Orientation
- Straight
- Kılıf / Paket
- 100
- Release Force
- 5.099gf
- Overtravel
- 0.030 (0.76mm)
- Ratings
- Dust Tight, IP67, Waterproof
- Voltage Rated Dc
- 30V
- Yayın Yılı
- 2004
- Operating Force
- 61gf
- Nem Hassasiyeti (MSL)
- Not Applicable
- Current Rating Amps
- 100mA AC/DC
- Contact Dc Max Rating R Load
- .1A@30VDC
- Circuit
- SPDT
- Max Voltage Rating Ac
- 125V
- Çalışma Sıcaklığı
- -20°C~70°C
- Contact Currentdcmax
- 0.1A
- Kurşunsuz
- Lead Free
- Operating Position
- 0.420 (10.7mm)
- Terminal
- Quick Connect
- Electricallife
- 200,000 Cycles
- Switch Function
- On-Mom
- Reach Svhc
- Unknown
- Max Current Rating
- 100mA
