D2SW-P01L2M

Teknik Özellikler

Overtravel

0.030 (0.76mm)

Yayın Yılı

2004

Voltage Rated Dc

30V

Ratings

Dust Tight, IP67, Waterproof

Max Voltage Rating Dc

30V

Seri

D2SW-P

Ambalaj

Bulk

Actuator Material

Polyacetal, Resin, Stainless Steel

Voltage Rated Ac

125V

Ingress Protection

IP67 - Dust Tight, Waterproof

Body Height

11mm

Depth

6.4mm

Contact Currentacmax

0.1A

Switch Type

SNAP ACTING/LIMIT SWITCH

ECCN Kodu

EAR99

Contact Materials

Gold

Montaj

Chassis Mount, Screw

Contact Current Rating

100mA

RoHS Durumu

RoHS Compliant

Release Force

5.099gf

Kılıf / Paket

100

HTS Kodu

8536.50.70.00

Terminal Stili

Wire Leads

Contact Ac Max Rating R Load

.1A@125VAC

Differential Travel

0.031 (0.8mm)

Actuator Type

Lever, Roller

Akım Değeri

100mA

Reach Svhc

Unknown

Parça Durumu

Active

Max Current Rating

100mA

Switch Function

On-Mom

Fabrika Tedarik Süresi

15 Weeks

Mechanical Life

1,000,000 Cycles

Montaj Tipi

Chassis Mount

Uzunluk

22.75mm

Contact Dc Max Rating R Load

.1A@30VDC

Current Rating Amps

100mA AC/DC

Operating Force

61gf

Nem Hassasiyeti (MSL)

1 (Unlimited)

Terminal

Wire
