Teknik Özellikler
- Terminal
- Wire Leads
- Electricallife
- 200,000 Cycles
- Operating Position
- 0.345 (8.8mm)
- Çalışma Sıcaklığı
- -20°C~70°C
- Contact Currentdcmax
- 0.1A
- Circuit
- SPDT
- Max Voltage Rating Ac
- 125V
- Contact Dc Max Rating R Load
- .1A@30VDC
- Current Rating Amps
- 100mA AC/DC
- Nem Hassasiyeti (MSL)
- Not Applicable
- Operating Force
- 61gf
- Fabrika Tedarik Süresi
- 19 Weeks
- Mechanical Life
- 1,000,000 Cycles
- Montaj Tipi
- Chassis Mount
- Actuator Travel
- 0.8 mm
- Body Length Or Diameter
- 19.8mm
- Differential Travel
- 0.031 (0.8mm)
- Actuator Type
- Lever, Straight
- Akım Değeri
- 100mA
- Reach Svhc
- Unknown
- Parça Durumu
- Active
- Switch Function
- On-Mom
- Body Breadth
- 6.4 mm
- Release Force
- 5.099gf
- Kılıf / Paket
- 100
- Orientation
- Straight
- HTS Kodu
- 8536.50.70.00
- Terminal Stili
- Wire Leads
- Contact Ac Max Rating R Load
- .1A@125VAC
- Max Voltage Rating Dc
- 30V
- Ambalaj
- Bulk
- Seri
- D2SW-P
- Ingress Protection
- IP67 - Dust Tight, Waterproof
- Voltage Rated Ac
- 125V
- Body Height
- 11mm
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Radyasyon Dayanımı
- No
- Contact Currentacmax
- 0.1A
- Contact Materials
- Gold
- ECCN Kodu
- EAR99
