Adet bazlı fiyat
- 1+ adet$0.89
- 10+ adet$0.84
- 100+ adet$0.80
- 500+ adet$0.75
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Actuator Travel
- 0.8 mm
- Body Length Or Diameter
- 19.8mm
- Fabrika Tedarik Süresi
- 7 Weeks
- Mechanical Life
- 1,000,000 Cycles
- Montaj Tipi
- Chassis Mount
- Reach Svhc
- Unknown
- Parça Durumu
- Active
- Switch Function
- On-Mom
- Body Breadth
- 6.4 mm
- Differential Travel
- 0.031 (0.8mm)
- Actuator Type
- Lever, Straight
- Akım Değeri
- 100mA
- Çalışma Sıcaklığı
- -20°C~70°C
- Contact Currentdcmax
- 0.1A
- Circuit
- SPDT
- Max Voltage Rating Ac
- 125V
- Terminal
- Solder
- Electricallife
- 200,000 Cycles
- Operating Position
- 0.345 (8.8mm)
- Operating Force
- 61gf
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Contact Dc Max Rating R Load
- .1A@30VDC
- Current Rating Amps
- 100mA AC/DC
- Voltage Rated Dc
- 30V
- Ratings
- Dust Tight, IP67, Waterproof
- Yayın Yılı
- 2004
- Overtravel
- 0.030 (0.76mm)
- Orientation
- Straight
- HTS Kodu
- 8536.50.70.00
- Contact Ac Max Rating R Load
- .1A@125VAC
- Terminal Stili
- Solder Lug
- Release Force
- 5.099gf
- Kılıf / Paket
- 100
- Contact Currentacmax
- 0.1A
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- ECCN Kodu
- EAR99
- Contact Materials
- Gold
- Montaj
- Chassis Mount, Panel, Screw, Solder
- Contact Current Rating
- 100mA
- RoHS Durumu
- RoHS Compliant
