Adet bazlı fiyat
- 1+ adet$2.07
- 10+ adet$1.95
- 100+ adet$1.84
- 500+ adet$1.74
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- ECCN Kodu
- EAR99
- Insulation Resistance
- 100MOhm
- Contact Current Rating
- 500mA
- Montaj
- Screw, Snap in, Through Hole
- Ingress Protection
- IP40
- Body Height
- 2.7mm
- Seri
- D2MQ
- Actuator Material
- Plastic
- HTS Kodu
- 8536.50.70.00
- Orientation
- Right Angle
- Overtravel
- 0.004 (0.1mm)
- Genişlik
- 2.6mm
- Voltage Rated Dc
- 30V
- Contact Resistance
- 100mOhm
- Operating Force
- 120gf
- Current Rating Amps
- 500mA DC
- Contact Dc Max Rating R Load
- .5A@30VDC
- Circuit
- SPDT
- Body Breadth
- 6.5 mm
- Max Current Rating
- 500mA
- Parça Durumu
- Active
- Actuator Type
- Round (Pin Plunger)
- Differential Travel
- 0.004 (0.1mm)
- Mechanical Life
- 30,000 Cycles
- Contact Materials
- Silver
- RoHS Durumu
- RoHS Compliant
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Radyasyon Dayanımı
- No
- Depth
- 9.2mm
- Max Voltage Rating Dc
- 30V
- Ambalaj
- Bulk
- Terminal Stili
- PC Pin
- Release Force
- 21gf
- Pretravelmax
- 0.4 mm
- Weight
- 300mg
- Yayın Yılı
- 2004
- Nem Hassasiyeti (MSL)
- Not Applicable
- Pretravel
- 0.015 (0.4mm)
- Çalışma Sıcaklığı
- -15°C~70°C
- Contact Currentdcmax
- 0.5A
