Adet bazlı fiyat
- 1+ adet$3.44
- 10+ adet$3.24
- 100+ adet$3.06
- 500+ adet$2.89
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Operating Position
- 0.606 (15.4mm)
- Ingress Protection
- IP67 - Dust Tight, Waterproof
- Montaj Tipi
- Chassis Mount
- Contact Currentdcmax
- 2A
- Orientation
- Straight
- Parça Durumu
- Active
- Current Rating Amps
- 100mA AC 2A DC
- Differential Travel
- 0.027 (0.7mm)
- Max Voltage Rating Dc
- 42V
- Release Force
- 5.099gf
- Çalışma Sıcaklığı
- -40°C~85°C
- Electricallife
- 100,000 Cycles
- Operating Force
- 92gf
- Montaj
- Chassis Mount, Panel, Screw, Wire
- Overtravel
- 0.110 (2.8mm)
- Max Voltage Rating Ac
- 125V
- Voltage Rated Ac
- 125V
- Voltage Rated Dc
- 12V
- Terminal Stili
- Wire Leads
- Throw Configuration
- SPST
- HTS Kodu
- 8536.50.70.00
- Ratings
- Dust Tight, IP67, Waterproof
- Kılıf / Paket
- 125
- Nem Hassasiyeti (MSL)
- Not Applicable
- Circuit
- SPST-NC
- Fabrika Tedarik Süresi
- 8 Weeks
- Body Breadth
- 5.3 mm
- Seri
- D2HW
- Akım Değeri
- 2A
- Contact Materials
- Gold
- Switch Function
- On-Mom
- Kurşunsuz Kodu
- yes
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Ambalaj
- Bulk
- Contact Current Rating
- 2A
- Reach Svhc
- Unknown
- Mechanical Life
- 1,000,000 Cycles
- Terminal
- Wire Leads
- Actuator Type
- Lever, Leaf
- ECCN Kodu
- EAR99
