Fiyat için teklif alın
Adet ve teslim süresine göre fiyatlandırılır.
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Ratings
- Dust Tight, IP67, Waterproof
- HTS Kodu
- 8536.50.70.00
- Throw Configuration
- SPST
- Voltage Rated Dc
- 12V
- Terminal Stili
- Wire Leads
- Overtravel
- 0.070 (1.8mm)
- Max Voltage Rating Ac
- 125V
- Voltage Rated Ac
- 125V
- Montaj
- Chassis Mount, Panel, Screw, Wire
- Operating Force
- 183gf
- Electricallife
- 100,000 Cycles
- Çalışma Sıcaklığı
- -40°C~85°C
- Max Voltage Rating Dc
- 42V
- Release Force
- 20gf
- Differential Travel
- 0.020 (0.5mm)
- Current Rating Amps
- 100mA AC 2A DC
- Parça Durumu
- Active
- Orientation
- Straight
- Contact Currentdcmax
- 2A
- Montaj Tipi
- Chassis Mount
- Ingress Protection
- IP67 - Dust Tight, Waterproof
- Operating Position
- 0.291 (7.4mm)
- Yayın Yılı
- 2004
- Body Height
- 6.5mm
- Contact Dc Max Rating R Load
- 2A@12VDC
- Body Length Or Diameter
- 18.5mm
- RoHS Durumu
- RoHS Compliant
- Actuator Travel
- 1.8 mm
- ECCN Kodu
- EAR99
- Actuator Type
- Lever, Leaf
- Terminal
- Wire Leads
- Mechanical Life
- 1,000,000 Cycles
- Reach Svhc
- Unknown
- Contact Current Rating
- 2A
- Ambalaj
- Bulk
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Switch Function
- On-Mom
- Kurşunsuz Kodu
- yes
- Contact Materials
- Gold
- Akım Değeri
- 2A
