Teknik Özellikler
- Parça Durumu
- Active
- Contact Currentdcmax
- 2A
- Orientation
- Straight
- Montaj Tipi
- Chassis Mount
- Ingress Protection
- IP67 - Dust Tight, Waterproof
- Insulation Resistance
- 100MOhm
- Voltage Rated Dc
- 12V
- Max Voltage Rating Ac
- 125V
- Operating Force
- 183gf
- Montaj
- Chassis Mount, Panel, Screw, Solder
- Electricallife
- 100,000 Cycles
- Release Force
- 20gf
- Max Voltage Rating Dc
- 42V
- Contact Current Rating
- 2A
- Contact Materials
- Gold, Silver
- Akım Değeri
- 2A
- Body Breadth
- 5.3 mm
- Circuit
- SPDT
- Fabrika Tedarik Süresi
- 20 Weeks
- Uzunluk
- 18.5mm
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Yayın Yılı
- 2004
- Contact Resistance
- 100mOhm
- ECCN Kodu
- EAR99
- Actuator Material
- Stainless Steel
- Reach Svhc
- No SVHC
- Differential Travel
- 0.020 (0.5mm)
- Current Rating Amps
- 100mA AC 2A DC
- Depth
- 8.3mm
- Operating Position
- 0.291 (7.4mm)
- Contact Plating
- Gold
- Max Current Rating
- 2A
- Ratings
- Dust Tight, IP67, Waterproof
- HTS Kodu
- 8536.50.70.00
- Terminal Stili
- Solder Lug
- Voltage Rated Ac
- 125V
- Overtravel
- 0.070 (1.8mm)
- Çalışma Sıcaklığı
- -40°C~85°C
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Ambalaj
- Bulk
