Teknik Özellikler
- Circuit
- SPDT
- Fabrika Tedarik Süresi
- 7 Weeks
- Body Breadth
- 5.3 mm
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Contact Current Rating
- 2A
- Akım Değeri
- 2A
- Contact Materials
- Gold, Silver
- Actuator Material
- Stainless Steel
- Reach Svhc
- Unknown
- Contact Resistance
- 100mOhm
- Yayın Yılı
- 2004
- ECCN Kodu
- EAR99
- Orientation
- Straight
- Contact Currentdcmax
- 2A
- Ingress Protection
- IP67 - Dust Tight, Waterproof
- Montaj Tipi
- Chassis Mount
- Parça Durumu
- Active
- Max Voltage Rating Ac
- 125V
- Montaj
- Chassis Mount, Panel, Screw, Solder
- Operating Force
- 66gf
- Electricallife
- 100,000 Cycles
- Max Voltage Rating Dc
- 42V
- Release Force
- 5.099gf
- Insulation Resistance
- 100MOhm
- Voltage Rated Dc
- 12V
- Genişlik
- 18.5mm
- Kılıf / Paket
- 125
- Sealing
- IP50
- Kurşunsuz Kodu
- yes
- Switch Function
- On-Mom
- Ambalaj
- Bulk
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Seri
- D2HW
- Terminal
- Solder
- Mechanical Life
- 1,000,000 Cycles
- Contact Dc Max Rating R Load
- 2A@12VDC
- Body Height
- 6.5mm
- Actuator Type
- Lever, Simulated Roller
- RoHS Durumu
- RoHS Compliant
- Depth
- 8.3mm
