Adet bazlı fiyat
- 1+ adet$3.08
- 10+ adet$2.91
- 100+ adet$2.74
- 500+ adet$2.59
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Ratings
- Dust Tight, IP67, Waterproof
- HTS Kodu
- 8536.50.70.00
- Terminal Stili
- Solder Lug
- Voltage Rated Ac
- 125V
- Overtravel
- 0.062 (1.6mm)
- Çalışma Sıcaklığı
- -40°C~85°C
- Differential Travel
- 0.020 (0.5mm)
- Current Rating Amps
- 100mA AC 2A DC
- Depth
- 8.3mm
- Operating Position
- 0.295 (7.5mm)
- Contact Plating
- Gold
- Max Current Rating
- 2A
- Body Height
- 6.5mm
- Contact Dc Max Rating R Load
- 2A@12VDC
- RoHS Durumu
- RoHS Compliant
- Actuator Type
- Lever, Straight
- Terminal
- Solder
- Mechanical Life
- 1,000,000 Cycles
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Ambalaj
- Bulk
- Switch Function
- On-Mom
- Kurşunsuz Kodu
- yes
- Seri
- D2HW
- Genişlik
- 3.4mm
- Kılıf / Paket
- 125
- Sealing
- IP50
- Insulation Resistance
- 100MOhm
- Voltage Rated Dc
- 12V
- Max Voltage Rating Ac
- 125V
- Operating Force
- 76gf
- Montaj
- Chassis Mount, Panel, Screw, Solder
- Electricallife
- 100,000 Cycles
- Release Force
- 7.138gf
- Max Voltage Rating Dc
- 42V
- Parça Durumu
- Active
- Contact Currentdcmax
- 2A
- Orientation
- Straight
- Montaj Tipi
- Chassis Mount
- Ingress Protection
- IP67 - Dust Tight, Waterproof
- Yayın Yılı
- 2004
