Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Ingress Protection
- IEC IP67
- Connection Method
- Connector
- Measurement Rangemax
- 1000 mm
- Material
- PBT
- REACH Uyumluluk Kodu
- unknown
- Çıkış Tipi
- ANALOG CURRENT
- Algılama Mesafesi
- 39.370 (1m)
- Max Supply Voltage Dc
- 24V
- Yükseklik
- 20mm
- Pin Sayısı
- 4
- Adjustment Type
- Single-Turn
- Yayın Yılı
- 2004
- RoHS Durumu
- RoHS Compliant
- Reach Svhc
- No SVHC
- Output Current
- 100mA
- Montaj
- Screw
- Fabrika Tedarik Süresi
- 5 Weeks
- Parça Durumu
- Active
- Output Range
- 100mA
- Output Configuration
- NPN - Dark-ON/Light-ON - Selectable
- Min Supply Voltage Dc
- 12V
- Sensorstransducers Type
- LINEAR POSITION SENSOR,PHOTOELECTRIC,DIFFUSE
- Light Source
- Infrared (860nm)
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Sensing Method
- Reflective, Diffuse
- Genişlik
- 10.8mm
- Çalışma Sıcaklığı
- -30°C~55°C
- Additional Feature
- IP 67 REVERSE POLARITY, SHORT CIRCUIT PROTECTION
- Response Time
- 1ms
- Besleme Gerilimi
- 12V~24V
- Ratings
- IP67
- Uzunluk
- 43.5mm
- Seri
- E3Z
