MPVZ5150GC7U

Teknik Özellikler

Yayın Yılı

2008

Maximum Pressure

58.02PSI (400kPa)

Yüzey Montaj

NO

Applications

Board Mount

Offsetnom

0.20V

Kılıf / Paket

8-DIP (0.550, 13.97mm), Top Port

HTS Kodu

8542.31

Port Size

Male - 0.13 3.17mm Tube

Output

0.2 V ~ 4.7 V

Terminal Stili

PC Pin

Body Height

12.955mm

Seri

MPVZ5150

Operating Pressure

21.76PSI (150kPa)

ECCN Kodu

EAR99

RoHS Durumu

ROHS3 Compliant

Çıkış Tipi

Analog Voltage

Body Length Or Diameter

10.665mm

Response Time

1000 μs

Sensorstransducers Type

PRESSURE SENSOR,PEIZORESISTIVE

Body Breadth

10.665 mm

Parça Durumu

Obsolete

Mounting Feature

THROUGH HOLE MOUNT

Pressure Sensing Mode

GAGE

Çalışma Sıcaklığı

-40°C~125°C

Pressure Rangemax

21.75 Psi

Port Style

Barbless

Housing

PLASTIC

Özellikler

Temperature Compensated

Pressure Type

Vented Gauge

Besleme Gerilimi

4.75V~5.25V

Nem Hassasiyeti (MSL)

Not Applicable
