MMBZ10VAL

Teknik Özellikler

Configuration

COMMON ANODE, 2 ELEMENTS

JESD-609 Kodu

e3

REACH Uyumluluk Kodu

unknown

Max Power Dissipation

360 mW

Casepackage

SOT-23

Terminal Formu

GULL WING

Rohs Code

Yes

Part Life Cycle Code

Transferred

Polarity

UNIDIRECTIONAL

Number Of Elements

2

Clamping Voltage

14.2 V

ECCN Kodu

EAR99

Uzunluk

3 mm

Jesd30 Code

R-PDSO-G3

Part Package Code

SOT-23

Ihs Manufacturer

NXP SEMICONDUCTORS

Risk Rank

5.74

Technology

AVALANCHE

Qualification Status

Not Qualified

Operating Supply Voltage

900 mV

Breakdown Voltagemax

10.5 V

Tepe Reflow Sıcaklığı (°C)

260

Max Breakdown Voltage

10.5 V

Nonrep Peak Rev Power Dismax

24 W

Reverse Standoff Voltage

6.5 V

Package Shape

RECTANGULAR

Peak Pulse Current

1.7 A

Genişlik

1.4 mm

Moisture Sensitivity Levels

1

Terminal Kaplaması

TIN

HTS Kodu

8541.10.00.50

Power Dissipation

265 mW

Ambalaj

Cut Tape

Terminal Pozisyonu

DUAL

Breakdown Voltage V

9.5 V

Montaj

Surface Mount

RoHS

Compliant

Pin Sayısı

3

Diode Element Material

SILICON

Esd Protection

Yes
