Adet bazlı fiyat
- 1+ adet$29.93
- 10+ adet$28.24
- 100+ adet$26.64
- 500+ adet$25.13
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Orientation
- Vertical
- Current Rating Amps
- 0.4VA AC/DC
- Voltage Rated Ac
- 28V
- REACH Uyumluluk Kodu
- unknown
- Switch Function
- On-On
- Fabrika Tedarik Süresi
- 8 Weeks
- Power Rating
- 400mW
- Montaj
- Front, Panel
- Kurşunsuz Kodu
- yes
- Montaj Tipi
- Panel Mount, Front
- Electricallife
- 100,000 Cycles
- Life Cycles
- 200000 cycles
- Terminal
- Solder
- Voltage Rated Dc
- 28V
- Illumination Color
- Green, Red
- ECCN Kodu
- EAR99
- Flammability Rating
- UL94 V-0
- Kurşunsuz
- Contains Lead
- Circuit
- DPDT
- Seri
- YB
- Çalışma Sıcaklığı
- -25°C~50°C
- Parça Durumu
- Active
- Color Actuatorcap
- Clear (White Filter/Diffuser)
- Yayın Yılı
- 2011
- Panel Cutout Dimensions
- Circular - 16.00mm Dia
- Tip
- Standard, Illuminated
- Ambalaj
- Tray
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Actuator Type
- Rectangular, Button
- Illumination Type Color
- LED, Red/Green
- Illumination Type
- LED
- Özellikler
- Epoxy Sealed Terminals
- Mechanical Life
- 200,000 Cycles
- Terminal Stili
- Solder, Quick Connect - 0.110 (2.8mm)
- Illumination Voltage Nominal
- 24VDC
- Housing Material
- Polyamide
- RoHS Durumu
- ROHS3 Compliant
- Contact Plating
- Gold
