Adet bazlı fiyat
- 1+ adet$15.83
- 10+ adet$14.94
- 100+ adet$14.09
- 500+ adet$13.30
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Ambalaj
- Tray
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Actuator Type
- Square, Button
- Yayın Yılı
- 2011
- Panel Cutout Dimensions
- Circular - 16.00mm Dia
- Contact Current Rating
- 3A
- Tip
- Standard
- Seri
- YB
- Çalışma Sıcaklığı
- -25°C~70°C
- Parça Durumu
- Active
- Color Actuatorcap
- Green (White Filter/Diffuser)
- Kurşunsuz
- Contains Lead
- Circuit
- DPDT
- RoHS Durumu
- ROHS3 Compliant
- Contact Plating
- Silver
- Housing Material
- Polyamide
- Akım Değeri
- 3A
- Terminal Stili
- Solder, Quick Connect - 0.110 (2.8mm)
- Özellikler
- Epoxy Sealed Terminals
- Mechanical Life
- 1,000,000 Cycles
- Kurşunsuz Kodu
- yes
- Montaj
- Front, Panel
- Montaj Tipi
- Panel Mount, Front
- Electricallife
- 100,000 Cycles
- Switch Function
- On-Mom
- Fabrika Tedarik Süresi
- 5 Weeks
- Voltage Rated Ac
- 125V
- REACH Uyumluluk Kodu
- unknown
- Orientation
- Vertical
- Current Rating Amps
- 3A AC/DC
- Flammability Rating
- UL94 V-0
- Terminal
- Solder
- Voltage Rated Dc
- 30V
- ECCN Kodu
- EAR99
- Life Cycles
- 1e+06 cycles
