Adet bazlı fiyat
- 1+ adet$16.45
- 10+ adet$15.51
- 100+ adet$14.64
- 500+ adet$13.81
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Max Current Rating
- 3A
- RoHS Durumu
- ROHS3 Compliant
- Electricallife
- 100,000 Cycles
- Depth
- 18mm
- Illumination Voltage Nominal
- 2.2VDC
- Seri
- YB
- Life Cycles
- 1e+06 cycles
- Circuit
- DPDT
- Parça Durumu
- Active
- Kurşunsuz
- Contains Lead
- Mechanical Life
- 1,000,000 Cycles
- Kurşunsuz Kodu
- yes
- Current Rating Amps
- 3A AC/DC
- Tip
- Standard, Illuminated
- Switch Function
- On-Mom
- Actuator Type
- Round, Button
- Illumination Type
- LED
- Montaj
- Front, Panel
- Flammability Rating
- UL94 V-0
- Illumination Type Color
- LED, Green
- Ambalaj
- Tray
- Montaj Tipi
- Panel Mount, Front
- Terminal
- Solder
- Max Voltage Rating Dc
- 30V
- Color Actuatorcap
- Clear (Green Filter/Diffuser)
- Contact Materials
- Silver
- Fabrika Tedarik Süresi
- 14 Weeks
- REACH Uyumluluk Kodu
- unknown
- Housing Material
- Polyamide
- Akım Değeri
- 3A
- Voltage Rated Ac
- 125V
- Terminal Stili
- Solder, Quick Connect - 0.110 (2.8mm)
- Uzunluk
- 18mm
- Panel Cutout Dimensions
- Circular - 16.00mm Dia
- Illumination Color
- Green
- Orientation
- Vertical
- Özellikler
- Epoxy Sealed Terminals
- Voltage Rated Dc
- 30V
- Yayın Yılı
- 2011
- ECCN Kodu
- EAR99
