Adet bazlı fiyat
- 1+ adet$32.06
- 10+ adet$30.24
- 100+ adet$28.53
- 500+ adet$26.91
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Contact Function
- ON-(ON)
- Ambalaj
- Bulk
- Montaj Tipi
- Panel Mount, Front
- Contact Dc Max Power Rating R Load
- 0.4VA@28VDC
- Terminal
- Solder
- Actuator Travel
- 2.9972 mm
- Color Actuatorcap
- Clear (White Filter/Diffuser)
- Insulation Materials
- DIALLYL PHTHALATE
- Montaj
- Front, Panel
- Seri
- YB2
- Circuit
- DPDT
- Center Contact Plating
- GOLD
- Parça Durumu
- Active
- Mechanical Life
- 1,000,000 Cycles
- Kurşunsuz Kodu
- yes
- Current Rating Amps
- 0.4VA AC/DC
- Contact Resistance
- 0.05mOhm
- Solderability
- HAND
- Tip
- Standard
- Actuator Type
- Round, Button, Flush
- Switch Function
- On-Mom
- Electricallife
- 100,000 Cycles
- RoHS Durumu
- ROHS3 Compliant
- Voltage Rated Dc
- 28V
- Yayın Yılı
- 2011
- ECCN Kodu
- EAR99
- End Contact Plating
- GOLD
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Length Termination
- 0.288 inch
- Çalışma Sıcaklığı
- -25°C~70°C
- Voltage Rated Ac
- 28V
- Terminal Stili
- Solder, Quick Connect - 0.110 (2.8mm)
- Panel Cutout Dimensions
- Circular - 22.00mm Dia
- Ingress Protection
- IP65 - Dust Tight, Water Resistant
- Özellikler
- Epoxy Sealed Terminals
- Terminal Material
- PHOSPHOR BRONZE
- Housing Material
- GLASS FILLED POLYAMIDE
- Ratings
- Dust Tight, IP65, Water Resistant
- Insulation Resistance
- 200000000Ohm
- Fabrika Tedarik Süresi
- 14 Weeks
