Adet bazlı fiyat
- 1+ adet$29.50
- 10+ adet$27.83
- 100+ adet$26.26
- 500+ adet$24.77
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Ratings
- Dust Tight, IP65, Water Resistant
- Housing Material
- Polyamide
- Throw Configuration
- DPDT, SPDT
- Fabrika Tedarik Süresi
- 14 Weeks
- Çalışma Sıcaklığı
- -25°C~50°C
- Max Voltage Rating Ac
- 250V
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- ECCN Kodu
- EAR99
- Yayın Yılı
- 2011
- Voltage Rated Dc
- 30V
- Özellikler
- Epoxy Sealed Terminals
- Orientation
- Vertical
- Ingress Protection
- IP65 - Dust Tight, Water Resistant
- Panel Cutout Dimensions
- Circular - 16.00mm Dia
- Uzunluk
- 18mm
- Terminal Stili
- Solder, Quick Connect - 0.110 (2.8mm)
- Voltage Rated Ac
- 125V
- Akım Değeri
- 3A
- Switch Function
- On-On
- Actuator Type
- Round, Button
- Tip
- Standard, Illuminated
- Current Rating Amps
- 3A AC/DC
- Kurşunsuz
- Contains Lead
- Kurşunsuz Kodu
- yes
- Mechanical Life
- 200,000 Cycles
- Parça Durumu
- Active
- Circuit
- SPDT
- Seri
- YB
- Illumination Voltage Nominal
- 3.3VDC
- Depth
- 18mm
- Electricallife
- 100,000 Cycles
- RoHS Durumu
- ROHS3 Compliant
- Max Current Rating
- 3A
- Contact Materials
- Silver
- Color Actuatorcap
- Clear (White Filter/Diffuser)
- Max Voltage Rating Dc
- 30V
- Terminal
- Solder
- Montaj Tipi
- Panel Mount, Front
- Ambalaj
- Tray
- Illumination Type Color
- LED, Green
