Adet bazlı fiyat
- 1+ adet$23.76
- 10+ adet$22.42
- 100+ adet$21.15
- 500+ adet$19.95
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Fabrika Tedarik Süresi
- 14 Weeks
- REACH Uyumluluk Kodu
- unknown
- Throw Configuration
- DPDT, SPDT
- Ratings
- Dust Tight, IP65, Water Resistant
- Terminal Stili
- Solder, Quick Connect - 0.110 (2.8mm)
- Kapasitans
- 0F
- Voltage Rated Ac
- 125V
- Akım Değeri
- 3A
- Özellikler
- Epoxy Sealed Terminals
- Orientation
- Vertical
- Illumination Color
- Orange
- Ingress Protection
- IP65 - Dust Tight, Water Resistant
- Panel Cutout Dimensions
- Circular - 16.00mm Dia
- ECCN Kodu
- EAR99
- Voltage Rated Dc
- 30V
- Yayın Yılı
- 2006
- Çalışma Sıcaklığı
- -25°C~50°C
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Electricallife
- 100,000 Cycles
- RoHS Durumu
- ROHS3 Compliant
- Illumination Voltage Nominal
- 2VDC
- Current Rating Amps
- 3A AC/DC
- Kurşunsuz
- Contains Lead
- Kurşunsuz Kodu
- yes
- Mechanical Life
- 200,000 Cycles
- Parça Durumu
- Active
- Circuit
- SPDT
- Seri
- YB
- Switch Function
- On-On
- Actuator Type
- Round, Button
- Tip
- Standard, Illuminated
- Contact Current Rating
- 3A
- Montaj
- Front, Panel, Sealed
- Illumination Type
- LED
- Terminal
- Solder
- Ambalaj
- Bulk
- Montaj Tipi
- Panel Mount, Front
- Illumination Type Color
- LED, Amber
- Flammability Rating
- UL94 V-0
- Contact Materials
- Silver
