Adet bazlı fiyat
- 1+ adet$27.03
- 10+ adet$25.50
- 100+ adet$24.06
- 500+ adet$22.70
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Current Rating Amps
- 0.4VA AC/DC
- Kurşunsuz
- Lead Free
- Kurşunsuz Kodu
- yes
- Mechanical Life
- 1,000,000 Cycles
- Parça Durumu
- Active
- Circuit
- SPDT
- Seri
- YB
- Switch Function
- On-Mom
- Actuator Type
- Rectangular, Button
- Tip
- Standard, Illuminated
- Electricallife
- 100,000 Cycles
- RoHS Durumu
- ROHS3 Compliant
- Illumination Voltage Nominal
- 3.6VDC
- Terminal
- Solder
- Ambalaj
- Bulk
- Montaj Tipi
- Panel Mount, Front
- Illumination Type Color
- LED, Blue
- Flammability Rating
- UL94 V-0
- Color Actuatorcap
- Clear (White Filter/Diffuser)
- Montaj
- Front, Panel
- Illumination Type
- LED
- Ratings
- Dust Tight, IP65, Water Resistant
- Housing Material
- Polyamide
- Contact Plating
- Gold
- Power Rating
- 400mW
- Fabrika Tedarik Süresi
- 14 Weeks
- ECCN Kodu
- EAR99
- Yayın Yılı
- 2011
- Voltage Rated Dc
- 28V
- Çalışma Sıcaklığı
- -25°C~50°C
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Terminal Stili
- Solder, Quick Connect - 0.110 (2.8mm)
- Voltage Rated Ac
- 28V
- Özellikler
- Epoxy Sealed Terminals
- Illumination Color
- Blue
- Ingress Protection
- IP65 - Dust Tight, Water Resistant
- Panel Cutout Dimensions
- Circular - 16.00mm Dia
