Adet bazlı fiyat
- 1+ adet$12.47
- 10+ adet$11.77
- 100+ adet$11.10
- 500+ adet$10.47
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Özellikler
- Epoxy Sealed Terminals
- Electricallife
- 10,000 Cycles
- Contact Ac Max Rating R Load
- 5A@250VAC
- Actuator Length
- 0.098 inch
- Actuator Material
- POLYCARBONATE
- Fabrika Tedarik Süresi
- 11 Weeks
- Contact Currentacmax
- 5A
- Kurşunsuz Kodu
- yes
- Yayın Yılı
- 2011
- Contact Plating
- Silver
- Contact Currentdcmax
- 5A
- Mechanical Life
- 200,000 Cycles
- Body Length Or Diameter
- 15.24mm
- Terminal Material
- BRASS
- Çalışma Sıcaklığı
- -20°C~70°C
- Body Breadth
- 15.24 mm
- Insulation Materials
- GLASS FILLED DIALLYL PHTHALATE
- Circuit
- DPDT
- Montaj Tipi
- Through Hole
- Montaj
- Through Hole
- Tip
- Standard
- Solderability
- WAVE
- Contact Voltageacmax
- 250V
- Contact Resistance
- 0.05mOhm
- Dielectric Withstanding Voltage
- 1500VAC V
- Reach Svhc
- No SVHC
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Color Actuatorcap
- Red
- Terminal Stili
- PC Pin
- Length Termination
- 0.157 inch
- RoHS Durumu
- ROHS3 Compliant
- Pcb Hole Count
- 8
- Insulation Resistance
- 200000000Ohm
- Illumination Type
- Illuminated
- Contact Current Rating
- 5A
- Terminal
- PC Pin
- Current Rating Amps
- 5A AC/DC
- ECCN Kodu
- EAR99
- Voltage Rated Dc
- 30V
- Actuator Type
- Square, Button
