Adet bazlı fiyat
- 1+ adet$10.59
- 10+ adet$9.99
- 100+ adet$9.43
- 500+ adet$8.90
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Body Height
- 16.4846mm
- Voltage Rated Dc
- 28V
- ECCN Kodu
- EAR99
- Montaj Tipi
- Through Hole
- Actuator Type
- Square, Button
- Montaj
- Through Hole
- Current Rating Amps
- 0.4VA AC/DC
- Circuit
- DPDT
- Terminal Material
- BRASS
- Çalışma Sıcaklığı
- -20°C~70°C
- Contact Resistance
- 0.1mOhm
- Voltage Rated Ac
- 28V
- Seri
- UB
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Dielectric Withstanding Voltage
- 1500VAC V
- Actuator Travel
- 2.3114 mm
- Parça Durumu
- Active
- Ambalaj
- Bulk
- Solderability
- WAVE
- Switch Function
- On-On
- Housing Material
- Polymer
- Tip
- Standard
- Max Current Rating
- 100mA
- RoHS Durumu
- ROHS3 Compliant
- Pcb Hole Count
- 8
- Uzunluk
- 15.24mm
- Color Actuatorcap
- Red
- Max Voltage Rating Ac
- 28V
- Terminal Stili
- PC Pin
- Depth
- 15.24mm
- Power Rating
- 400mW
- Özellikler
- Epoxy Sealed Terminals
- Max Voltage Rating Dc
- 28V
- Electricallife
- 200,000 Cycles
- Contact Plating
- Gold
- Terminal
- PC Pin
- Mechanical Life
- 200,000 Cycles
- Throw Configuration
- DPDT, SPDT
- Yayın Yılı
- 2009
- Contact Materials
- Copper
