Adet bazlı fiyat
- 1+ adet$11.14
- 10+ adet$10.51
- 100+ adet$9.92
- 500+ adet$9.35
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Color Actuatorcap
- Green
- Terminal Stili
- PC Pin
- RoHS Durumu
- ROHS3 Compliant
- Length Termination
- 0.157 inch
- Pcb Hole Count
- 6
- Insulation Resistance
- 200000000Ohm
- Terminal
- PC Pin
- Current Rating Amps
- 5A AC/DC
- ECCN Kodu
- EAR99
- Voltage Rated Dc
- 30V
- Actuator Type
- Square, Button
- Body Height
- 16.4846mm
- Akım Değeri
- 5A
- Switch Function
- On-Mom
- Housing Material
- GLASS FILLED REINFORCED NYLON
- Actuator Travel
- 2.3114 mm
- Parça Durumu
- Active
- Ambalaj
- Bulk
- Voltage Rated Ac
- 125V
- Seri
- UB
- Özellikler
- Epoxy Sealed Terminals
- Contact Function
- ON-(ON)
- Electricallife
- 10,000 Cycles
- Contact Ac Max Rating R Load
- 5A@250VAC
- Actuator Length
- 0.098 inch
- Actuator Material
- POLYCARBONATE
- Fabrika Tedarik Süresi
- 5 Weeks
- Kurşunsuz Kodu
- yes
- Contact Currentacmax
- 5A
- Yayın Yılı
- 2011
- Contact Currentdcmax
- 5A
- Contact Plating
- Silver
- Mechanical Life
- 1,000,000 Cycles
- Throw Configuration
- DPDT, SPDT
- Terminal Material
- BRASS
- Body Length Or Diameter
- 15.24mm
- Body Breadth
- 15.24 mm
- Çalışma Sıcaklığı
- -20°C~70°C
- Insulation Materials
- GLASS FILLED DIALLYL PHTHALATE
- Circuit
- DPDT
