UB226SKG035C-1JB

Teknik Özellikler

Actuator Travel

2.3114 mm

Parça Durumu

Active

Ambalaj

Bulk

Voltage Rated Ac

28V

Seri

UB2

Genişlik

15mm

Housing Material

Polyamide

Switch Function

On-On

Voltage Rated Dc

28V

ECCN Kodu

EAR99

Actuator Type

Square, Button

Flammability Rating

UL94 V-0

Body Height

10.0076mm

Current Rating Amps

0.4VA AC/DC

Illumination Color

Red

Terminal

PC Pin

Insulation Resistance

200000000Ohm

Illumination Type

Illuminated, LED

Uzunluk

15.2mm

RoHS Durumu

ROHS3 Compliant

Color Actuatorcap

Clear (White Filter/Diffuser)

Power Rating

400mW

Terminal Stili

PC Pin

Contact Resistance

0.1mOhm

Dielectric Withstanding Voltage

1000VAC V

Nem Hassasiyeti (MSL)

1 (Unlimited)

Illumination Voltage Nominal

1.85VDC

Tip

Standard, Illuminated

Solderability

WAVE

Montaj Tipi

Through Hole

Montaj

Through Hole

Terminal Material

PHOSPHOR BRONZE

Çalışma Sıcaklığı

-25°C~50°C

Body Breadth

15.24 mm

JESD-609 Kodu

e4

Circuit

DPDT

Yayın Yılı

2009

Contact Plating

Gold

Mechanical Life

200,000 Cycles

Orientation

Vertical
