Adet bazlı fiyat
- 1+ adet$31.65
- 10+ adet$29.86
- 100+ adet$28.17
- 500+ adet$26.57
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Flammability Rating
- UL94 V-0
- Montaj Tipi
- Panel Mount, Snap-In
- Actuator Type
- Square, Button
- Montaj
- Panel, Snap in
- Voltage Rated Dc
- 28V
- ECCN Kodu
- EAR99
- JESD-609 Kodu
- e4
- Çalışma Sıcaklığı
- -25°C~50°C
- Circuit
- DPDT
- Current Rating Amps
- 0.4VA AC/DC
- Ambalaj
- Bulk
- Parça Durumu
- Active
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Illumination Voltage Nominal
- 3.5VDC
- Seri
- UB2
- Voltage Rated Ac
- 28V
- Tip
- Standard, Illuminated
- Switch Function
- On-On
- Housing Material
- Polyamide
- Life Cycles
- 200000 cycles
- RoHS Durumu
- ROHS3 Compliant
- Electricallife
- 200,000 Cycles
- Illumination Type Color
- LED, Green
- Özellikler
- Epoxy Sealed Terminals
- Panel Cutout Dimensions
- Square - 17.40mm2
- Terminal Stili
- Solder Lug
- Power Rating
- 400mW
- Color Actuatorcap
- Clear (White Filter/Diffuser)
- Illumination Color
- Green
- Yayın Yılı
- 2009
- Mechanical Life
- 200,000 Cycles
- Terminal
- Solder
- Contact Plating
- Gold
- Fabrika Tedarik Süresi
- 8 Weeks
- Illumination Type
- Illuminated, LED
- Kurşunsuz Kodu
- yes
