Adet bazlı fiyat
- 1+ adet$30.32
- 10+ adet$28.60
- 100+ adet$26.98
- 500+ adet$25.46
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- ECCN Kodu
- EAR99
- Voltage Rated Dc
- 28V
- Montaj
- Through Hole
- Actuator Type
- Square, Button
- Montaj Tipi
- Through Hole
- Flammability Rating
- UL94 V-0
- Current Rating Amps
- 0.4VA AC/DC
- Circuit
- DPDT
- Çalışma Sıcaklığı
- -25°C~50°C
- JESD-609 Kodu
- e4
- Seri
- UB2
- Voltage Rated Ac
- 28V
- Illumination Voltage Nominal
- 3.3VDC
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Ambalaj
- Bulk
- Parça Durumu
- Active
- Housing Material
- Polyamide
- Switch Function
- On-Mom
- Tip
- Standard, Illuminated
- RoHS Durumu
- ROHS3 Compliant
- Color Actuatorcap
- Clear (White Filter/Diffuser)
- Power Rating
- 400mW
- Terminal Stili
- PC Pin
- Özellikler
- Epoxy Sealed Terminals
- Illumination Type Color
- LED, White
- Electricallife
- 200,000 Cycles
- Terminal
- PC Pin
- Contact Plating
- Gold
- Mechanical Life
- 1,000,000 Cycles
- Yayın Yılı
- 2009
- Illumination Color
- White
- Kurşunsuz Kodu
- yes
- Illumination Type
- Illuminated, LED
- Fabrika Tedarik Süresi
- 8 Weeks
