Adet bazlı fiyat
- 1+ adet$16.45
- 10+ adet$15.52
- 100+ adet$14.64
- 500+ adet$13.82
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Actuator Travel
- 2.3114 mm
- Parça Durumu
- Active
- Ambalaj
- Bulk
- Voltage Rated Ac
- 125V
- Seri
- UB2
- Terminal Kaplaması
- Gold (Au)
- Genişlik
- 15mm
- Housing Material
- Polyamide
- Switch Function
- On-Mom
- ECCN Kodu
- EAR99
- Voltage Rated Dc
- 30V
- Actuator Type
- Square, Button
- Flammability Rating
- UL94 V-0
- Body Height
- 10.0076mm
- Akım Değeri
- 5A
- Current Rating Amps
- 5A AC/DC
- Contact Current Rating
- 5A
- Illumination Color
- Red
- Terminal
- Solder
- Insulation Resistance
- 200000000Ohm
- Illumination Type
- Illuminated, LED
- Uzunluk
- 19mm
- RoHS Durumu
- ROHS3 Compliant
- Color Actuatorcap
- Clear (White Filter/Diffuser)
- Terminal Stili
- Solder Lug
- Contact Resistance
- 0.05mOhm
- Kılıf / Paket
- 125
- Dielectric Withstanding Voltage
- 1000VAC V
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Illumination Voltage Nominal
- 1.85VDC
- Tip
- Standard, Illuminated
- Solderability
- WAVE
- Contact Voltageacmax
- 250V
- Montaj
- Panel, Snap in
- Montaj Tipi
- Panel Mount, Snap-In
- Terminal Material
- PHOSPHOR BRONZE
- Çalışma Sıcaklığı
- -25°C~50°C
- JESD-609 Kodu
- e4
- Body Breadth
- 15.24 mm
- Circuit
- DPDT
