UB215SKG035C-1JB

Teknik Özellikler

Illumination Color

Red

Terminal

PC Pin

Insulation Resistance

200000000Ohm

Illumination Type

LED

Uzunluk

15.2mm

RoHS Durumu

ROHS3 Compliant

Color Actuatorcap

Clear (White Filter/Diffuser)

Terminal Stili

PC Pin

Power Rating

400mW

Actuator Travel

2.3114 mm

Parça Durumu

Active

Ambalaj

Bulk

Seri

UB2

Voltage Rated Ac

28V

Genişlik

15mm

Switch Function

On-Mom

Housing Material

Polyamide

Voltage Rated Dc

28V

ECCN Kodu

EAR99

Flammability Rating

UL94 V-0

Actuator Type

Square, Button

Body Height

10.0076mm

Current Rating Amps

0.4VA AC/DC

Yayın Yılı

2009

Contact Plating

Gold

Mechanical Life

1,000,000 Cycles

Orientation

Vertical

Fabrika Tedarik Süresi

8 Weeks

Center Contact Material

COPPER

Kurşunsuz Kodu

yes

Kurşunsuz

Contains Lead

Washability

SOLVENT

Illumination Type Color

LED, Red

Özellikler

Epoxy Sealed Terminals

End Contact Material

COPPER

Contact Function

ON-(ON)

Electricallife

200,000 Cycles

Contact Resistance

0.1mOhm

Nem Hassasiyeti (MSL)

1 (Unlimited)

Illumination Voltage Nominal

1.85VDC
