Adet bazlı fiyat
- 1+ adet$10.44
- 10+ adet$9.85
- 100+ adet$9.29
- 500+ adet$8.77
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Throw Configuration
- DPDT, SPDT
- Mechanical Life
- 200,000 Cycles
- Contact Currentdcmax
- 5A
- Contact Plating
- Gold
- Terminal
- Solder
- Yayın Yılı
- 2011
- Kurşunsuz Kodu
- yes
- Contact Currentacmax
- 5A
- Insulation Resistance
- 200000000Ohm
- Fabrika Tedarik Süresi
- 11 Weeks
- Sealing
- EPOXY
- Length Termination
- 0.197 inch
- RoHS Durumu
- ROHS3 Compliant
- Actuator Length
- 0.154 inch
- Terminal Stili
- Solder Lug
- Color Actuatorcap
- White
- Contact Ac Max Rating R Load
- 5A@250VAC
- Electricallife
- 10,000 Cycles
- Panel Cutout Dimensions
- Rectangular - 22.40mm x 16.20mm
- Özellikler
- With Barrier
- Dielectric Withstanding Voltage
- 1500VAC V
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Contact Resistance
- 0.05mOhm
- Voltage Rated Ac
- 125V
- Seri
- UB
- Kılıf / Paket
- 125
- Parça Durumu
- Active
- Ambalaj
- Bulk
- Actuator Travel
- 2.3114 mm
- Housing Material
- GLASS FILLED POLYAMIDE
- Switch Function
- On-On
- Contact Voltageacmax
- 250V
- Tip
- Standard
- Body Height
- 17.526mm
- Akım Değeri
- 5A
- Montaj Tipi
- Panel Mount, Snap-In
- Actuator Type
- Rectangular, Button
- Montaj
- Panel, Snap in
- ECCN Kodu
- EAR99
- Voltage Rated Dc
- 30V
