Adet bazlı fiyat
- 1+ adet$9.84
- 10+ adet$9.28
- 100+ adet$8.75
- 500+ adet$8.26
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Fabrika Tedarik Süresi
- 5 Weeks
- Orientation
- Vertical
- Kurşunsuz Kodu
- yes
- Contact Materials
- Copper
- Yayın Yılı
- 2009
- Mechanical Life
- 1,000,000 Cycles
- Contact Plating
- Gold
- Electricallife
- 200,000 Cycles
- Contact Function
- ON-(ON)
- Max Voltage Rating Dc
- 28V
- Özellikler
- Epoxy Sealed Terminals
- Illumination Type Color
- LED, Amber
- Depth
- 15.24mm
- Kurşunsuz
- Contains Lead
- Max Current Rating
- 100mA
- Tip
- Standard, Illuminated
- Dielectric Withstanding Voltage
- 1500VAC V
- Illumination Voltage Nominal
- 2VDC
- Reach Svhc
- No SVHC
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Contact Dc Max Power Rating R Load
- 0.4VA@28VDC
- Contact Resistance
- 0.05mOhm
- Çalışma Sıcaklığı
- -25°C~50°C
- Terminal Material
- PHOSPHOR BRONZE
- Circuit
- SPDT
- Montaj Tipi
- Through Hole
- Montaj
- Through Hole
- Insulation Resistance
- 200000000Ohm
- Illumination Type
- LED
- Illumination Color
- Orange
- Terminal
- PC Pin
- Terminal Stili
- PC Pin
- Max Voltage Rating Ac
- 28V
- Color Actuatorcap
- Clear (White Filter/Diffuser)
- Uzunluk
- 15.24mm
- Pcb Hole Count
- 5
- RoHS Durumu
- ROHS3 Compliant
- Housing Material
- Polymer
- Switch Function
- On-Mom
- Ambalaj
- Tray
